Engine / Drive Train Specifications

Engine: 140cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 9.39HP/7500RPM

Max Torque: 7ft-lb/5500RPM

Bore × Stroke: 56.5mm x 55.5mm

Compression Ratio: 9.4:1

Cooling System:  Oil cooled

Transmission:  Fully Automatic

Start System:  Electric Start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 59.03MPH

Battery: 12V5Ah



Frame / Body / Suspension / Brakes

Front Suspension:  Dual inverted hydraulic forks and shock absorbers.

Rear Suspension:  Swing arm with dual air bag shock absorbers.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake

Front Tires: 130/70-12

Rear Tires: 140/70-12



Capacities / Dimensions

Max Load: 286.65lbs

Gross Weight: 275.63lbs

Net Weight: 222.71lbs

Overall Length: 68.9inches

Overall Width: 31.5inches

Overall Height: 40.16inches

Carton Dimensions (L × W × H):  62.6x18.11x33.86inches

Seat Height: 28.35inches

Wheelbase: 47.88inches

Ground Clearance: 7.09inches

Gas Tank Capacity: 1.64gal

Fuel Consumption: 94.09mpg



Available colors:  Black/Gray, Orange/Blue.
