Engine / Drive Train Specifications

Engine: 302.5cc, 4-valves, 4-stroke, Balance shaft

Cylinder Arrangement: Single cylinder

Max Horsepower: 26.82HP/8500RPM

Max Torque: 18.44ft-lb/6500RPM

Bore × Stroke: 77mm x 65mm

Compression Ratio: 11.0:1

Cooling System:  Water cooled

Transmission:  6-Speed, Manual

Start System:  Electric Start

Ignition: BOSCH Electronic Fuel Injection

Final Drive: Chain drive

Max Speed: 88MPH

Battery:  12V8.6Ah







Frame / Body / Suspension / Brakes

Front Suspension:  Dual inverted hydraulic forks and shock absorbers.

Rear Suspension:  Swing arm with central shock absorber.

Front Brake: Hydraulic disc brake

Rear Brake: Hydraulic disc brake

Front Tires: 110/70-17 Alloy Rim

Rear Tires: 140/70-17 Alloy Rim



Capacities / Dimensions

Max Load: 330.75lbs

Gross Weight: 357.21lbs

Net Weight:  304.29lbs

Overall Length: 79.93inches

Overall Width: 32.29inches

Overall Height: 48.63inches

Carton Dimensions (L × W × H):  69.69x19.69x33.86inches

Seat Height: 31.11inches

Wheelbase:  55.32inches

Ground Clearance: 7.48inches

Gas Tank Capacity:  3.83gal

Fuel Consumption: 58.8mpg



Available colors:  Grey/Black, Green/Black
